Pigment fjólublátt 23-Corimax Violet RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

Tæknilegar breytur Pigment violet 23

Litavísitala nr.Pigment fjólublátt 23.
Vöru NafnCorimax Violet RLS
VöruflokkurLífrænt litarefni
Léttleiki (húðun)7
Hitaþol (húðun)200
Léttleiki (plast)7
Hitaþol (plast)250
Litur
Pigment-fjólublátt-23-litur
Hue dreifinguskv

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

Lögun:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

Forrit :

Mælt með fyrir bíla málningu, byggingarmál húðun, spóluhúð, iðnaðarmálningu, dufthúðun, prentunarpasta, PVC, gúmmí, PS, PP, PE, PU, offsetblek, vatnsbannað blek, leysiefni, UV blek.

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
————————————————————————————————————————————————— ———————————————

Tengdar upplýsingar

Eðlis- og efnafræðilegir eiginleikar:
Litur eða ljós: blár fjólublár
Hlutfallslegur þéttleiki: 1,40-1,60
Magnþéttleiki / (lb / gal): 11,7-13,3
Bræðslumark / ℃: 430-455
Meðal agnastærð / míkró: 0,04-0,07
Agna lögun: tenings / stöng
Sérstakt yfirborðsflatarmál / (m2 / g): 45-102
pH gildi / (10% slurry): 6,2

Vörunotkun:Pigment fjólublátt 23 er aðallega notað til litunar á húðun, blek, gúmmíi og plasti, og einnig til litunar á tilbúnum trefjum
Það eru 124 tegundir af auglýsingamerkjum af litarefninu. Carbazoazine er eins konar blátt fjólublátt afbrigði með sterka og óvenjulega notkun og sérstakt yfirborð flatarmónólíts fjólublátt RN er 74m2 / g. Það er mikið notað á ýmsum sviðum eins og húðun, blekprentun, plast- og dúkprentun og litun. Það hefur góða festu til að lakka þegar litað er. Það er hægt að nota fyrir loftþurrkun málningu, bifreiðmálningu OEM og bökunarmálningu, sérstaklega fyrir latexmálningu með CuPc andlitsvatni og sterkum ljósum tón. Það er hægt að nota til plastlitunar, með hitaþol 280 ℃ í pólýólefíni og mikilli litavarðhald (aðeins 0,07% af styrk litarefnis er þörf fyrir HDPE með 1 / 3SD); það er einnig hægt að nota til litunar á pólýester og PE.

Tilgangsregla: Karbazól er notað sem hráefni og N-etýring er framkvæmd við venjulegan þrýsting í viðurvist fasahverfis hvata og nitrunarviðbrögð og afoxunarviðbrögð eru framkvæmd til að mynda 2-amínó-N-etýlkarbazól; 3,5,6-tetrachloroparaquinone (Chloranil) er látin þéttast og loka efnahvörfum, síað, þvegið með vatni og þurrkað til að fá hráan karbazól fjólublátt; að lokum, almenn litarefmeðferð með því að hnoða eða hnoða til að fá CI litarefni fjólublátt 23.

samheiti :Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

Sameindauppbygging:Pigment-fjólublátt-23-sameinda uppbygging
